0.76mm PVB Film for Automobile Wind Glass Grey On Green Color

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Browse by Category

Contact us

Qingdao Jiahua Plastics CO.,LTD
[China]

Address
No.1777 century Av.,Haibin industrial park of Huangdaodist., Qingdao Shandong
Phone
86-130-70822105
Contact name
Joanna Wei

Quick Information

  • Brand Name: sagelayer
  • Place of Origin: China
  • Model Number : pvb film
  • thickness : 0.76mm
  • width : 600-1900mm
  • length : 200m
  • Certificate : Ce/SGS/ISO9001
  • Visible Light Transmittance : 80% Min
  • Haze : 0.4%
  • Moisture Content : 0.35-0.55%
  • Tensile Strength : Min 20MPa

Description

0.76mm PVB Film for Automobile Wind Glass Grey On Green Color

Product Descripition

Jiahua PVB film interlayer is a macromolecule material which produced by extrusion using PVB resin, plasticizer and additives. Saflayer pvb film is not only can shield out the UV, heat and sound, but also famous for its high visible transmittance, super anti-penetration. The major application of PVB film  is laminated safety glass used on automotive windshields, architectural glass as well as the bullet proof glass.

Product Parameters

Thickness0.76mm
AppearanceSurfaceSmooth surface without Nick,Crease,Bond; The color band should be evenly distributed and the width of transitional region is equalized
Band ColorClear, Blue,Green ,Gray & others
Crystallite and watermarks Crystallite Diameter exceed 2.0mm is not allowed. No visible watermarks.
Visible defects (impurities, bubbles, oil, drop etc.) Defects Diameter exceed 0.5mm and
allowed maximum 6 defects per 200m
Defects Diameter exceed 0.5mm to tag on PVB film; Diameter less than 0.5mm in the Intensive defects area* must tag on one defect. The defects marks and places should be showed in the packing list.

Thickness tolerance(mm)Plus or Minus 0.04mm
Thickness and sizeUniformity ratioAt any two points from 25mm distance either horizontally or vertically of the thickness tolerance is less than 15μm; (or 50mm - less than 25μm; or 100mm - less than 50μm)

Length (m)Normal length

Width (mm)Normal width
Roughness Rz15 -70
Moisture content (%)0.35 - 0.55
Heat shrinkage rate
( 60ºC/15min) (%)
8.0 Max
Pummel value7 Max
Light transmittance (%)85 Min
Haze (%)0.2 - 0.4
UV Screening, up to 380nm (%)99
Tensile strength  (MPa )20.0 Min
Tensile elongation (% )200 Min
Yellowness index (%)10 Max
*Intensive defects area: Within the 300mm diameter circle, the defect numbers is over 10 and its interval less than 5 mm.
Company Profile

Qingdao Jiahua Plastics Co., ltd. is a professional manufacturer and engaged in the research & production, sale and service of  PVB resin, PVB film interlayer, PVB plasticizer (3GO) and Float laminated glass sheets. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. Going with company development, we are looking for new team of partner with strong integrity to join us to enjoy our business together.

Product Package

Packing: The pvb film is rolled by insulated with PE film and then wrapping film, cased into an aluminum foil bag by vacuum sealed, and then packing into plywood box or fiber can. (remark: The width is less than 1250mm, which can be packing into fiber can)


Price

  • Delivery Port : Qingdao China

Packaging & Delivery

  • Packing :in roll
  • Delivery Lead Time : in 20 days
  • Supply Ability : 60rolls/day

Product Image

  • 0.76mm PVB Film for Automobile Wind Glass Grey On Green Color image
